Gate and Door App

Gate and Door App is an on-premises gate and door access management system with remote capabilities for home and office use.

Gate and Door App gives homeowners and businesses the ability to assign individual and unique user access codes that are used to control access to properties. The application takes the user information and securely transfers the access data to the access control boards. The access controllers are connected to the keypads, card readers or QR code scanners that your visitors use to key or swipe into the property.

Our application is available on several platforms such as Windows and Linux (not compatible with Mac computers), with Android and iOS apps coming soon. For more information or an estimate please contact us.

Camera and keypad

Gate and Door App can be used to lock and unlock more than just gates and doors. It can be used to control pickup or delivery lockers, safe rooms, private dining rooms, meeting rooms, rental party rooms, commercial kitchens, secured parking lots/garages, or anything you can dream up!

Parking solutions

GateAndDoor.App SaaS feature enhancements

Our Software as a Service (SaaS) GateAndDoor.App improves upon the existing Gate and Door App technology with the following capabilities:

Configuration (v2.0.0)

Local network access controller search and easy configure
Configure Zones, Departments, Personnel, Access Privileges and Time Profiles

Operation (v2.0.0)

Upload users to control boards for user access
Check, adjust time, and monitor all doors and gates
Download and query swipe records
Export and print swipe records

Remote Open (v2.0.0)

Authenticated users can remote open any door on demand.

Attendance (v2.1.0)

Set shift rules, shift types, holiday, leave / business trip settings
Manual sign in/out option
Attendance reporting

Presence (v2.2.0)

Uses an in and an out swiping point at each door.
Persons inside can be reported on with the use of entrance/exit access control point pairs.

Patrol (v2.3.0)

Set patrol points, patrol rules, patrolmen and routes.
Patrolmen can physically scan a "nail" (Access Device) along their predefined route.
Patrol reports

Meals (v2.4.0)

Setup meal readers, rules, periods and cost
Report access and cost by readers or departments

Meetings (v2.5.0)

Set meeting address, readers, schedule and content of meeting
Report and/or monitor meeting attendance

Fingerprint Access (v2.6.0)

Fingerprint management via on-premises USB fingerprint readers or manual upload of fingerprint files
10 fingerprints per user recommended

Video Management Software (VMS) (v2.7.0)

NVR/DVR system scales from a single camera to as many as your installation needs
Works with a large list of IP, USB and analog cameras
Suitable for home, small business, and multi-server enterprise deployments
Monitor cameras from anywhere

Automatic License Plate Recognition (ALPR) (v2.8.0)

Works with streaming video and/or image uploads
Auto open gates with ALPR camera integration
2MP camera minimum, 4MP or higher recommended
Cameras and network must support RTSP streams
Notifications of entry with image, plate number, vehicle type, make, model, color, region, direction of travel and orientation

Gate And Door App (GADA) Mifare® Classic 1k Access Credentials (v3.0.0)

Use on-premises hardware (Mifare® reader/writers) to encode and re-encode compatible access credentials: Mifare® printable membership ID cards (CR-80), employee badges (CR-80), vendor badges (CR-80), key fobs, wristbands, etc.

Reservation system integration

Gate and Door App works with Campground Master™ and other reservation systems, with improvements that make it easier to use with many integrations.

Compatible hardware

Compatible hardware for Gate and Door App v2: please contact us directly for control boards, keypads, card readers and credentials. Compatible hardware for Gate and Door App v3 will be available on this website soon.

Gate and Door App control board

Gate and Door App v2+ compatible
Communication: Wired TCP/IP + UDP
Power supply input: DC/12V
Input format of reader: Wiegand 26 bit (all 125kHz or 13.56MHz card readers with compatible protocol)
Quantity of readers: 1–4 units; doors controlled: 1–4
Quantity of users: 20,000; event buffers (offline): 100,000
Max distance from reader to controller: 100m/328ft (suggested 80m/262ft)
Offline operation, real-time supervision, photo display with valid card
Note: Not compatible with some encrypted cards (e.g. HID, Indala, Cobra, APCiK, Paradox, Radio, Honeywell).

Gate and Door App RFID keypad

Gate and Door App v2 compatible; Wiegand 26-bit output, 125kHz RFID input
Power: DC/12V; waterproof IP66
Cable: 22 AWG min., length not exceeding 100 meters; reading distance up to 6cm

Gate and Door App RFID keyfob / RFID cards (125kHz)

Standard EM card (Tk4100), CR-80 for cards; read-only, not programmable
Not compatible with UHF and encrypted readers (e.g. HID, Indala, Cobra, etc.).

Gate and Door App keypad reader combo (Mifare®)

Gate and Door App v3+ compatible; Mifare® 13.56MHz RFID; Wiegand 26-bit output; DC/12V, IP66

GateAndDoor.App service level comparison

Feature	Free Trial	Premium	Deluxe	Business
Control Board Simulator	✓	✓	✓	✓
Configuration	✓	✓	✓	✓
Operation	✓	✓	✓	✓
Remote Open	✓	✓	✓	✓
125 kHz RFID	✗	✓	✓	✓
Attendance	✗	✓	✓	✓
Presence	✗	✓	✓	✓
Patrol	✗	✗	✓	✓
Video Management	✗	✗	✓	✓
License Plate Recognition	✗	✗	✓	✓
Mifare® 13.56MHz RFID	✗	✗	✗	✓
Fingerprint Access	✗	✗	✗	✓
Meals	✗	✗	✗	✓
Meetings	✗	✗	✗	✓

Campground Master™ notice

Campground Master™ is a trademark owned by Cottonwood Software. Its use on this site is strictly for educational purposes. Manual excerpts within our courses and lessons are copyrighted works of Campground Master™ and/or Cottonwood Software; their use on this site is strictly for educational purposes. GateAndDoor.App is not affiliated nor endorsed by Campground Master™ or Cottonwood Software. We are a VAR (Value Added Reseller), systems integrator and software trainer of Campground Master™ and other reservation and supporting technologies.
